Austro Engine E4 Series User Manual

E4 Series
Maintenance Manual
Engine Control
System
E4.08.04
Rev.29
Page 207
76 - Maintenance Procedures
01-Jul-2020
5. Camshaft Sensor CAS 1
A. Remove the Camshaft Sensor CAS 1
Detail Steps/Work Items
Key Items/References
(1)
Remove the injector cover.
Refer to Section 85-10-00 Paragraph
3.A.
(2)
Pull down the electrical connector CAS1.
Disconnect the pigtails.
(3)
Remove the locking screw from the sensor and
the blade terminal attached to the locking
screw.
Refer to Fig. 76 - 12.
(4)
Pull out the camshaft sensor.
B. Install the Camshaft Sensor CAS 1
Detail Steps/Work Items
Key Items/References
(1)
Lubricate the new O-Ring with engine oil.
Refer to Consumable list.
(2)
Push the sensor into the cylinder head cover.
Make sure the O-Ring is in correct
position.
(3)
Install shielding to the CAS1 sensor screw:
- E4A(B)95-000-000 rev. AC.1 or lower: Ring terminal
- E4A(B)95-000-000 rev. AD.1 or higher: Single blade [12] terminal
When using Loctite, make sure that the thread is free of grease.
Apply a thin film of Loctite.
(4)
Tighten the locking screw of the camshaft
sensor.
Torque 10 Nm. Apply Loctite 243.
Refer to Fig. 76 - 12.
(5)
Make sure the sensor is in correct position.
(6)
Connect the electrical connector CAS 1.
(7)
For blade terminal connection (only with engine harness E4A(B)-95-000-000 rev. AD.1
or higher):
- attach the pigtail CAS1.
For CAS2 installed under the injector cover (Refer to Fig. 76 - 14):
- connect the ring terminal of CAS2 to blade terminal CAS1
- connect CAS1 flat terminal to CAS2 flat terminal (double connection)
(8)
Install the injector cover.
Refer to Section 85-10-00 Paragraph
3.B.
(9)
Do an engine ground run.
Refer to Section 71-00-01.
