E4 Series
Maintenance Manual
Engine Oil
System
E4.08.04
Rev. 29
Page 231
79-Maintenance Procedures
01-Jul-2020
Detail Steps/Work Items
Key Items/References
- One more sealing ring
Tighten the banjo bolt into the connection fitting.
(6)
Install lock-wire between the banjo bolt and the
connection fitting.
Refer to the standard procedures.
(7)
Apply rubber grease on the new O-Rings.
Put them on the connection fitting.
Refer to Fig. 79 - 26.
Do not contaminate the inner of the cylinder head!
(8)
Remove the cover from the specified position of
the banjo bolt/adapter assembly at the cylinder
head.
(9)
Push the banjo bolt/adapter assembly into the
specified cylinder head opening.
Refer to Fig. 79 - 27.
(10)
Install the turbocharger oil return line.
Refer to Paragraph B.
