E4 Series
Maintenance Manual
Turbocharging
E4.08.04
Rev. 29
Page 209
81- Maintenance Procedures
01-Jul-2020
Fig. 81 - 12 Turbocharger engine configuration “-A”
Fig. 81 - 13 Wastegate connection rod precautions
Wastegate pin
Hose
Clamp
Wastegate
controller
Screw
Spring loaded
circlip
