Austro Engine E4 Series

To Next Page

To Previous Page

E4 Series

Maintenance Manual

Reciprocating

Engine

Page 240

E4.08.04

Rev. 29

85-Maintenance Procedures

01-Jul-2020

Fig. 85 - 57 Centering pins

Fig. 85 - 58 Bearing friction ring position check

between 3 and 6 mm

Correct position of the ring
