E4 Series

Maintenance Manual

Reciprocating

Engine

E4.08.04

Rev. 29

Page 269

85-Maintenance Procedures

01-Jul-2020

Fig. 85 - 95 Exploded view of Intake Air Manifold (Configuration B)

Screw

Gasket

BPS

Screw

Intake Air Manifold

Temp.

Sensor (CTS)

Sealing ring

Collar screw

Coolant

thermostat

Screw

O-Ring

Hose connection

Sealing ring

Spacer

Pressure

sensor (BPS)

Temp.

Sensor (IAT)

Sealing ring
