E4 Series
Maintenance Manual
Reciprocating
Engine
Page 328
E4.08.04
Rev. 29
85-Maintenance Procedures
01-Jul-2020
Fig. 85 - 148 Connection of the new chain ends and the open link
Fig. 85 - 149 Chain clip positioned in the chain closing tool
Open chain link
Pressure pad
Chain clip
