Austro Engine E4 Series User Manual

E4 Series
Maintenance Manual
Reciprocating
Engine
Page 342
E4.08.04
Rev. 29
85-Maintenance Procedures
01-Jul-2020
3. Heat Exchanger
A. Remove the heat exchanger
Detail Steps/Work Items
Key Items/References
(1)
Remove the oil filter housing drain line.
Refer to Section 79-20-00 Paragraph
4.A.
(2)
Remove the oil filter housing.
Refer to Section 79-20-00 Paragraph
2.A.
(3)
Remove the five screws from the heat
exchanger.
Refer to Fig. 85 - 162.
(4)
Remove the heat exchanger.
(5)
Clean the sealing surface.
B. Install the heat exchanger
Detail Steps/Work Items
Key Items/References
(1)
Install a new gasket.
(2)
Put the heat exchanger in position on the
engine.
Refer to Fig. 85 - 162.
(3)
Tighten the five screws on the heat
exchanger.
Torque 9 Nm.
(4)
Install the oil filter housing.
Refer to Section 79-20-00 Paragraph
2.B.
(5)
Install the oil filter housing drain line.
Refer to Section 79-20-00 Paragraph
4.B.
(6)
Clean the working area.
(7)
Do a check of the oil level.
Refer to Section 12-10-00.
(8)
Do an engine ground run.
Refer to Section 71-00-01.
(9)
Examine the oil and coolant system for
leakage.
