Austro Engine E4 Series User Manual

E4 Series
Maintenance Manual
Additional
Information
E4.08.04
Rev. 29
Page 15
92 – Special Tools
01-Jul-2020
92-20-00 Special Tools
Title
Tool
Remark
AE 300 Wizard
EECU Software Read Out Program
The user guide E4.08.09 of the AE 300 Wizard will
be delivered with the program
For installation and
usage of the
Software, refer to
the user guide
E4.08.09.
Flywheel Locking
Tool
Refer to
Section 85-10-00
Removal of the
Two–Mass-
Flywheel
Injector removal
tool
After removal of
the clamping shoe
(refer to Section
73-10-01 Removal
of the Injector
point 6), the tool
has to be
positioned with the
end “X” of the tool
below the injector
nut.
Then the injector
can be loosened
with a hint of the
“weight” to the
upper end “Y” of
the tool in upward
direction.
weight
X
Y
