5.3.7 Enabling replaced components in the BIOS
When an expansion card fails, the defective component will be set to Disabled
or Failed in the BIOS. The server will then reboot with only the intact hardware
components remaining in the system configuration.
●
Communication between BIOS and iRMC temporarily failed during the
POST.
●
Booting to execute iRMC Emergency Flash.
In this cases, the defective component needs to be reenabled in the BIOS after
replacing it.
▶
Enter the BIOS.
▶
Select the
Configuration menu.
▶
Select the status menu of the desired component:
▶
Select PCI Status for expansion cards.
▶
Reset replaced components to Enabled.
▶
Save your changes and exit the BIOS.
For more information on how to access the BIOS and modify settings,
see the corresponding BIOS Setup Utility reference manual.
5.3.8 Verifying the system time settings
This task only applies to Linux and VMware environments.
After the system board has been replaced, the system time is set automatically.
By default, the RTC (Real T
ime Clock) time standard is set as the local time.
Basic software procedures
100 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
