Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

▶
Inform the customer about changed WWN, MAC and SAS addresses, see
"Looking for MAC/WWN/GUID and SAS addresses" on page 107
.
▶
"Updating the NIC configuration file in a Linux and VMware environment" on
page 104.
▶
"Updating expansion card firmware" on page 95.
▶
"Resuming BitLocker functionality" on page 105.
▶
If applicable, reconfigure your network settings in the operation system
according to the original configuration of the replaced controller (expansion
card or onboard).
Configuration of network settings should be performed by the
customer. For more information, see
"Note on network settings
recovery" on page 286.
▶
If applicable, restore LAN teaming configurations, see "After replacing or
upgrading LAN controllers" on page 1
14.
9.8.4 Replacing a riser card
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 49
.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
▶
"Locating the defective component" on page 50.
▶
Remove the corresponding riser module, see "Removing a riser module" on
page 70.
Expansion cards and backup units
288 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
