Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

7.5.7 Replacing a 2.5-inch PCIe SSD module
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: – Installation frame included: tool-less
–
Installation frame excluded: Phillips PH1 / (+) No. 1 screw driver
This procedure is valid, if the PCIe SSD module is controlled by an
onboard controller and the VMD function is enabled in the BIOS. For
more information, see the "Intel Virtual RAID on CPU (Intel VROC) User
Guide".
If the PCIe SSD module is controlled by a RAID controller of the PRAID
EP5xxi/CP5xxi/EP6xxi family
, the PCIe SSD module can be installed
during operation (hot-plug), see "Removing 2.5-inch HDD/SSD
modules" on page
168.
CAUTION
All HDD/SSD modules (drives) must be uniquely identified so that they
can be reinstalled in their original bays later. If this is not done, existing
data can be lost.
Preliminary steps
▶
"Locating the defective server" on page 49.
▶
If applicable, "Removing the front cover with lock" on page
52.
▶
Identify the physical location of the PCIe SSD module, see "Overview of
configurations" on page 159.
▶
Prepare the removing of the PCIe SSD module.
▶
Depending on your configuration and OS: "Shutting down the server" on
page 52.
Hard disk drive (HDD) / solid state disk (SSD)
178 Upgrade and Maintenance Manual RX2540 M6
