Figure 294: Installing the front panel cage (B)
▶
Push the locking latch in the direction of the arrow to lock the front panel
cage.
Concluding steps
▶
"Installing the fan cage" on page
76
.
▶
"Reassembling" on page 60.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 69.
▶
If applicable, "Installing the front cover with lock" on page 69.
▶
"Resuming BitLocker functionality" on page 105.
13.4.3 Replacing the LTO drive
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Accessible drives
426 Upgrade and Maintenance Manual RX2540 M6
