Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

16.6 M.2 SSD
16.6.1 Slots and bolts for M.2 SSDs
The system board of
fers two M.2 slots (Key M) with support for 80 mm and 110
mm long M.2 SSDs. With the M.2 SSD an internal SSD is offered. This SSD
can be configured as a boot device or data storage device.
iRMC
S5
external connectors
INDICATE
CSS
TPM
Battery
Slot 8 (CPU 2) Riser slot 2
Rear Serial
Front Panel
PSU2
JP3
1
JP2 JP1
1
2
Micro
SD
USB
3.0
SSD2
M.2
HDD LED2
Slot 7 (CPU2)
Slot 6 (CPU2)
Front VGA
Slot 5 (CPU2)
OCP 3.0 Slot 1 (CPU1)
SSD1
M.2
L
AN
Ma
nagement
Internal USB3.0/
USB 3
Rear VGA
CPU 2
CPU 1
CPU 1 DIMM 2A
CPU 1 DIMM 1D
CPU 1 DIMM 1C
CPU 1 DIMM 2C
CPU 1 DIMM 1A
CPU 1 DIMM 2D
CPU 1 DIMM 2B
CPU 1 DIMM 1B
CPU 2 DIMM 1R
CPU 2 DIMM 2N
CPU 2 DIMM 2P
CPU 2 DIMM 1P
CPU 2 DIMM 2R
CPU 2 DIMM 1N
CPU 2 DIMM 1Q
CPU 2 DIMM 2Q
CPU 1 DIMM 2H
CPU 1 DIMM 1G
CPU 1 DIMM 2G
SMB 4
SLIMLINE
4 (CPU 2)
LC2
PWR10
HDD LED3
HDD
LED1
PWR4PWR3PWR2
SLIMLINE
3 (CPU 2)
SLIMLINE
2 (CPU 1)
SLIMLINE
1 (CPU 1)
FAN5_SYS
FAN4_SYS
FAN3_SYS
FAN2_SYS
ROC
VROC
SMB 3
Clear RTC
PCH
Slot riser card
Riser card
Slot 10
Slot 9
Figure 347: Slots for M.2 SSDs
▶
Identify the physical location according to the following table.
(SAT
A mode: AHCI)
M.2 SSD slot BIOS menu iRMC SEL
1 M.2 SSD1 SSATA Port 4 (M.2 Slot 1) Port 1
2 M.2 SSD2 SSATA Port 2 (M.2 Slot 0) Port 0
(SATA mode: RAID)
M.2 SSD slot BIOS menu iRMC SEL
1 M.2 SSD1 Port 4 Port 4
2 M.2 SSD2 Port 2 Port 2
System board and components
RX2540 M6 Upgrade and Maintenance Manual 497

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
