9.5 OCP (Open Compute Project) modules
9.5.1 Position of the OCP module
Figure 144: Position of OCP module at rear side
1 OCP module
There are different OCP modules available.
Some OCP modules can be equipped with SFP modules, see
"Handling SFP+ transceiver modules" on page 239.
9.5.2
Installing an OCP module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Expansion cards and backup units
RX2540 M6 Upgrade and Maintenance Manual 249
