Installing the new ODD
▶
Install the ODD, see "Installing the ODD (2.5-inch chassis)" on page 387.
Concluding steps
▶
"Reassembling" on page
60.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 69.
▶
If applicable, "Installing the front cover with lock" on page 69.
▶
"Resuming BitLocker functionality" on page 105.
13.3.5 Installing the ODD (3.5-inch chassis)
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for cover 2)
– T
orx Plus 6 screw driver (not valid for Japan)
– Phillips PH1 / (+) No. 1 screw driver (Japan)
Preliminary steps
▶
"Suspending BitLocker functionality" on page
87
.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
Accessible drives
RX2540 M6 Upgrade and Maintenance Manual 395
