9.3 Handling slot brackets
9.3.1 Installing slot brackets
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Use the low profile bracket perforated for relevant controllers. No
bracket needed for installing the internal RAID controller in the internal
RAID riser module.
Figure 132: Perforated and non-perforated slot brackets
1 Full height bracket non-perforated
2 Full height bracket perforated
3
Low profile bracket perforated
Expansion cards and backup units
RX2540 M6 Upgrade and Maintenance Manual 237
