13 Accessible drives
13.1 Safety notes
CAUTION
▶
Before installing an accessible drive, acquaint yourself with the
drive's user documentation.
▶
When inserting an accessible drive into the server, ensure not to
pinch or strain any connected cables.
▶
When installing an accessible drive, hold it by its sides. Applying
force to the top of the casing may cause failures.
▶
When disposing of, transferring, or returning a backup drive, ensure
that all backup media has been removed from the drive.
▶
Circuit boards and soldered parts of internal options are exposed
and can be damaged by static electricity. Always discharge static
build-up (e.g. by touching a grounded object) before handling
electrostatic-sensitive devices (ESDs).
▶
Do not touch the circuitry on boards or soldered parts. Hold circuit
boards by their metallic areas or edges.
▶
For more information, see "Important information" on page 35
.
13.2 Basic information
Depending on the type of system, the PRIMERGY RX2540 M6 offers:
●
one 5.25-inch accessible drive bay for ODDs
●
one bay (optional) for an L
TO drive or a RDX drive
ODD drive is not available for 12x 3.5-inch HDD versions, 24x 2.5-inch
HDD versions and 64x EDSFF versions.
LT
O drive or RDX drive are not available for 3.5-inch HDD versions, 24x
2.5-inch HDD versions and 64x EDSFF versions.
RX2540 M6 Upgrade and Maintenance Manual 385
