Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

–
iRMC microSD card
–
M.2 SSDs
–
Dual microSD 64GB Enterprise
–
PCIe riser modules
Components that are handled solely as Repair Units
–
CMOS battery
2.2.4
Field Replaceable Units (FRU)
Field Replaceable Units (FRU)
Removing and installing Field Replaceable Units involves complex
maintenance procedures on integral server components. Procedures will
require shutting down, opening and disassembling the server.
CAUTION
Maintenance procedures involving Field Replaceable Units must be
performed exclusively by Fujitsu service personnel or technicians
trained by Fujitsu. Please note that unauthorized interference with the
system will void the warranty and exempt the manufacturer from all
liability.
Components that are handled as Field Replaceable Units
–
CPU (replacement)
–
HDD backplane (SAS/SAT
A/PCIe SSD) or EDSFF SSD backplane
–
SAS expander board / PCIe switch board
–
PCIe riser card
–
Common Operation Panel (COP)
–
System board
–
Trusted Platform Module (TPM)
Before you start
28 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
