Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

7.7 Rear HDD/SSD extension box
7.7.1 Positions of rear HDD cages
Figure 112: Positions of rear HDD cages
1 HDD cage 1 2 HDD cage 2
7.7.2 Upgrading with rear HDD cage 1
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Software: 10 minutes
Tools:
– Phillips PH2 / (+) No. 2 screw driver
–
Phillips PH1 / (+) No. 1 screw driver
Hard disk drive (HDD) / solid state disk (SSD)
212 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
