Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 49
.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
▶
"Removing the fan cage" on page 74.
Removing the defective SAS expander board
▶
Disconnect all cables from the SAS expander board.
▶
Remove the SAS expander board, see "Removing the SAS expander
board" on page 210.
Installing the new SAS expander board
▶
Install the SAS expander board, see "Installing the SAS expander board" on
page 205.
▶
Connect the cables to the SAS expander board, see Figure 109.
Concluding steps
▶
"Installing the fan cage" on page 76.
▶
"Reassembling" on page 60.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 69.
▶
If applicable,"Installing the front cover with lock" on page 69.
Hard disk drive (HDD) / solid state disk (SSD)
RX2540 M6 Upgrade and Maintenance Manual 211

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
