Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page 52
.
▶
Identify the physical location of the EDSFF SSD module, see "Overview of
configurations" on page 188.
▶
Prepare the removing of the EDSFF SSD module.
▶
Depending on your OS: "Shutting down the server" on page 52.
Removing an EDSFF SSD module
Figure 96: Opening the locking lever
▶
Pinch the green locking clips (1) and open the locking lever (2).
▶
Pull the EDSFF SSD module completely out of its bay
.
Hard disk drive (HDD) / solid state disk (SSD)
194 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
