Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

1 OOB cable
2 Power cable
3 Slimline cable
4 Slimline cable
For the cable plan, see "Appendix B" on page 571.
▶
Install the top SSD backplane, see "Installing the new 16x EDSFF SSD
backplane (top)" on page 198
.
Concluding steps
▶
"Installing the fan cage" on page 76.
▶
Insert all EDSFF SSD modules, see "Installing an EDSFF SSD module" on
page 192.
Make sure that you reinstall the EDSFF SSD module in the bay it was
located before the SSD backplane replacement.
▶
Insert all dummy modules, see "Installing an EDSFF SSD module" on
page
192
.
▶
"Reassembling" on page 60.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 69.
▶
If applicable, "Installing the front cover with lock" on page 69.
7.6 SAS expander board
7.6.1 Installing the SAS expander board
The SAS expander board is an option for the 12x 3.5-inch HDD
configuration, the 16x 2.5-inch HDD/SSD configuration and the 24x 2.5-
inch HDD/SSD configuration.
Hard disk drive (HDD) / solid state disk (SSD)
204 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
