Remove the two screws (see circles).
▶
Remove the ODD latch.
▶
If no new ODD will be installed:
▶
Fasten the ODD latch with two screws to the chassis (see Figure 255).
Installing the dummy cover
Figure 278: Installing the dummy cover
▶
Insert the dummy cover and push it inward until it engages at the other side.
Concluding steps
▶
"Reassembling" on page
60
.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 69.
▶
If applicable, "Installing the front cover with lock" on page 69.
▶
"Resuming BitLocker functionality" on page 105.
13.3.7 Replacing the ODD (3.5-inch chassis)
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Accessible drives
RX2540 M6 Upgrade and Maintenance Manual 409
