Fujitsu PRIMERGY RX2540 M6

7.5.1.4 Configuration with rear 2.5-inch HDD/SSD/PCIe modules
Figure 73: Configuration with up to 6x 2.5-inch rear HDDs/SSDs/PCIe SSDs
HDD/SSD modules
Position Logical drive
number
ServerView RAID Manager display
name
[0] 0 Vendor Product (0)
[1] 1 Vendor Product (1)
[2] 2 Vendor Product (2)
[3] 3 Vendor Product (3)
[4] 4 Vendor Product (4)
[5] 5 Vendor Product (5)
PCIe SSD modules
Position Logical drive
number
ServerView RAID Manager display
name
[0] - Intel PCIe Device Adapter (device serial
number): Vendor Product
[1] - Intel PCIe Device Adapter (device serial
number): Vendor Product
[2] - Intel PCIe Device Adapter (device serial
number): Vendor Product
[3] - Intel PCIe Device Adapter (device serial
number): Vendor Product
Hard disk drive (HDD) / solid state disk (SSD)
164 Upgrade and Maintenance Manual RX2540 M6
