9.9.2 Removing a GPU card from a riser module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Suspending BitLocker functionality" on page 87
.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
▶
Remove all riser modules, see "Removing a riser module" on page 70.
▶
"Removing an expansion card from a riser module" on page 284.
▶
If necessary, remove the cables from the expansion cards.
▶
"Removing the air duct" on page 78.
▶
Disconnect the GPU power cable from the system board connector.
Removing the GPU card from a riser module (example NVDIA Tesla A100)
GPU A40/A6000 have the same removement procedure.
Expansion cards and backup units
RX2540 M6 Upgrade and Maintenance Manual 307
