17 Appendix A
17.1 Mechanical overview
17.1.1
Server front
17.1.1.1 3.5-inch HDD configuration
Figure 367: Front side 10x 3.5-inch HDDs
Figure 368: Front side 12x 3.5-inch HDDs
1 Front VGA
2 ODD / dummy cover
3
Common Operation Panel
4 HDDs / dummy modules
RX2540 M6 Upgrade and Maintenance Manual 535

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
