Insert the riser card.
▶
Fasten the riser card with two screws (see circles).
▶
Install the expansion card, see "Installing the expansion card into the
internal RAID riser module" on page
267
.
▶
Install the internal RAID riser module, see "Installing the internal RAID riser
module" on page 271.
Concluding steps
▶
"Installing the fan cage" on page 76.
▶
"Reassembling" on page 60.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 69.
▶
If applicable, "Installing the front cover with lock" on page 69.
9.8 Expansion cards in riser modules
9.8.1 Installing an expansion card in a riser module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
–
Phillips PH1 / (+) No. 1 screw driver
Preliminary steps
▶
"Suspending BitLocker functionality" on page 87
.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
Expansion cards and backup units
280 Upgrade and Maintenance Manual RX2540 M6
