Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

●
iRMC microSD card
The iRMC microSD card is necessary for using the embedded Lifecycle
Management (eLCM) functionality of the iRMC.
●
M.2 SSD
The system board of
fers two M.2 slots (Key M) with support 80 mm and
1
10 mm long M.2 SSDs. With the M.2 SSD an internal SSD is offered. This
SSD can be configured as a boot device or data storage device.
●
Dual microSD 64GB Enterprise
The system board is optionally equipped with a Dual microSD 64GB
Enterprise. The Dual microSD 64GB Enterprise offers an Integrated
Hardware RAID solution based on RAID-on-Chip (ROC) technology.
●
VROC module
The VROC module is necessary for using the VROC functionality. VROC
provides RAID solutions for NVMe SSDs and SATA devices.
16.3 CMOS battery
16.3.1 Replacing the CMOS battery
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for cover 2)
– recommended: tooth pick (CMOS battery)
For this server the battery type CR2450 is used.
System board and components
476 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
