Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

4.7 Connecting the power cord
4.7.1 Connecting the power cord (AC PSU)
CAUTION
The AC PSU adjusts automatically to any mains voltage in the range
from 100
V - 240 V (AC PSU Platinum) or 200 V - 240 V (AC PSU
Titanium).
▶
You may only operate the server if its rated voltage range
corresponds to the local mains voltage.
▶
Connect the power cord to the PSU.
▶
If applicable, connect the main plug to an power outlet of the rack socket
strip.
To provide true phase redundancy, the second PSU should be
connected to a different AC power source from the other PSU. If one
AC power source should fail, the server will still continue to run.
▶
Ensure that the status indicator on the PSU is lit green, see "Indicator on
hot-plug PSU" on page
565.
You can secure the power cord with a cable clamp to ensure that the
power cord cannot be disconnected from the server by mistake.
Basic hardware procedures
RX2540 M6 Upgrade and Maintenance Manual 65

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
