Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

5.3.15 Configuring LAN teaming
Using ServerView Operations Manager
▶
Use the ServerV
iew Operations Manager to obtain more information on
existing LAN teams:
▶
In ServerView Operations Manager Single System View select System
Status from the Information/Operation menu.
▶
Under Network Interfaces select LAN Teaming.
▶
The Network Interfaces (Summary) overview shows all configured LAN
teams and their components. Choose a LAN team to display further
details:
LAN Team Properties: Properties of the selected LAN team
LAN Team Statistics: Available statistics about the selected LAN team
For more information, see the "ServerView Operations Manager - Server
Management" user guide.
Using Infrastructure Manager
When using Infrastructure Manager and replacing LAN controller or system
board, you have to deapply the profile before replacing and apply the profile
again after replacing.
Please refer to the following manuals of the Infrastructure Manager.
See manual "FUJITSU Software Infrastructure Manager Vx.x.x User's
Guide", section "2.4.2 Profiles and Policies", available at:
https://ts.fujitsu.com/support/
For Japan:
See manual "FUJITSU Software Infrastructure Manager Vx.x.x 解説書",
section "2.4.2 プロファイルとポリシー", available at:
https://www.fujitsu.com/jp/products/software/infrastructure-software/
infrastructure-software/serverviewism/technical/
Basic software procedures
RX2540 M6 Upgrade and Maintenance Manual 113

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
