9 SAS/SATA cable (rear HDD backplane)
10 SAS/SATA cable (rear HDD backplane)
11 Signal cable
12 Power cable
For the cable plan, see "Appendix B" on page 571.
Concluding steps
▶
"Installing the fan cage" on page 76
.
▶
"Reassembling" on page 60.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 69.
▶
If applicable,"Installing the front cover with lock" on page 69.
7.6.2 Removing the SAS expander board
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page
49
.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
▶
"Removing the fan cage" on page 74.
Hard disk drive (HDD) / solid state disk (SSD)
208 Upgrade and Maintenance Manual RX2540 M6
