Insert the front VGA cable in the cable clip (see circle).
▶
Connect the front VGA cable to the system board connector "Front VGA".
Concluding steps
▶
"Installing the air duct" on page
79.
▶
"Installing the fan cage" on page
76.
▶
If applicable, "Installing the riser module 1" on page 72.
▶
"Reassembling" on page 60.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 69.
▶
If applicable, "Installing the front cover with lock" on page 69.
14.4.2 Removing the front VGA
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for cover 2)
– hexagon screw driver 5 mm (for front VGA)
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page 52
.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
▶
If applicable, "Removing the riser module 1" on page 70.
▶
"Removing the fan cage" on page 74.
▶
"Removing the air duct" on page 78.
Front panel
RX2540 M6 Upgrade and Maintenance Manual 457
