Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

▶
Install the lower slot cover.
Concluding steps
▶
"Installing the cross bar" on page
81.
▶
"Installing the air duct" on page 79.
▶
If applicable, install the corresponding riser module, see "Installing a riser
module" on page 72.
▶
If applicable, install the corresponding rear air grid, see "Installing a rear air
grid" on page 84.
▶
"Reassembling" on page 60.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 69.
▶
If applicable, "Installing the front cover with lock" on page 69.
▶
If applicable, update the system information of your server using the Chassis
ID Prom Tool, see "Using the Chassis ID Prom Tool" on page 110.
▶
"Resuming BitLocker functionality" on page 105.
9.9.3 Replacing a GPU card from a riser module
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Note on network settings recovery
When replacing network controllers, network configuration settings in
the OS will be lost and replaced by default values. This applies to all
static IP address and LAN teaming configurations.
Ensure to note down your current network settings before replacing a
network controller.
Expansion cards and backup units
312 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
