Start the ServerView RAID Manager and log in.
▶
Select the desired SAS controller
.
In the General tab you can find data on the selected object including its SAS
address.
For more information, see the "ServerView Operations Manager -
Server Management" user guide and the "ServerView RAID
Manager" user guide.
▶
Inform the customer about the new SAS address. The customer need the
new SAS address, especially when the server is connected to a Fujitsu
Storage ETERNUS system.
5.3.14
Using the Chassis ID Prom T
ool
The Common Operation Panel (COP) contains the Chassis ID EPROM that
stores the following system information:
–
server name and model
–
housing type
–
serial number
–
manufacturing data
–
information depending on the configuration:
– installed HDD/SSD/EDSFF backplanes
– installed rear HDD/SSD cages
– installed expansion cards (for example EP5xxi)
In order to integrate your system into the ServerView Management
environment and to enable server installation using the ServerView Installation
Manager, system information needs to be completed and corrected.
Basic software procedures
110 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
