Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Installing the new OCP module
▶
Install the OCP module, see "Installing the OCP module" on page 251.
Concluding steps
▶
"Connecting the power cord" on page
65.
▶
"Switching on the server" on page 69.
▶
If applicable, "Installing the front cover with lock" on page 69.
▶
Inform the customer about the changed MAC addresses, see "Looking for
MAC/WWN/GUID and SAS addresses" on page 107.
▶
"Updating the NIC configuration file in a Linux and VMware environment" on
page 104.
▶
"Configuring LAN teaming" on page 113.
9.6 Expansion cards in standard PCIe slots
9.6.1 Installing an expansion card
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Suspending BitLocker functionality" on page 87
.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
Expansion cards and backup units
RX2540 M6 Upgrade and Maintenance Manual 255

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
