7.5.2 Installing 2.5-inch HDD/SSD modules
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page 52
.
▶
Locate the correct drive bay, see "Overview of configurations" on page 159.
Removing a 2.5-inch HDD/SSD dummy module
Unusable HDD bays contain a HDD/SSD dummy with dummy lock to
prevent customer from erroneously adding a HDD.
Hard disk drive (HDD) / solid state disk (SSD)
RX2540 M6 Upgrade and Maintenance Manual 165
