Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

9.9 GPU cards in riser modules
9.9.1 Installing a GPU card in a riser module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
– Phillips PH1 / (+) No. 1 screw driver
Preliminary steps
▶
"Suspending BitLocker functionality" on page 87
.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
▶
Remove all riser modules, see "Removing a riser module" on page 70.
▶
If no riser module is installed: Remove the corresponding rear air grid, see
"Removing a rear air grid" on page 82.
▶
"Removing the air duct" on page 78.
▶
"Removing the cross bar" on page 80.
Installing the GPU card in a riser module (example NVDIA Tesla A100)
GPU A40/A6000 have the same installation procedure.
Expansion cards and backup units
RX2540 M6 Upgrade and Maintenance Manual 291

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
