Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Figure 270: Locking the ODD cage
▶
Lock the ODD cage with the green latch (see close-up).
Concluding steps
▶
"Reassembling" on page
60.
▶
"Connecting the power cord" on page
65.
▶
"Switching on the server" on page 69.
▶
If applicable, "Installing the front cover with lock" on page 69.
▶
"Resuming BitLocker functionality" on page 105.
13.3.6 Removing the ODD (3.5-inch chassis)
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Accessible drives
402 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
