Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Removing the defective 2.5-inch PCIe SSD module
▶
Remove the PCIe SSD module, see "Removing a 2.5-inch PCIe SSD
module" on page 176.
▶
If applicable, remove the PCIe SSD from the installation frame, see
"Handling HDDs or SSDs without installation frame" on page
136.
Installing the new 2.5-inch PCIe SSD module
▶
If applicable, install the PCIe SSD in the installation frame, see "Handling
HDDs or SSDs without installation frame" on page 136.
▶
Install the PCIe SSD module, see "Installing 2.5-inch PCIe SSD modules"
on page 172.
Concluding steps
▶
If applicable, "Switching on the server" on page 69.
▶
If applicable, rescan available devices from your OS.
▶
If applicable, "Installing the front cover with lock" on page 69.
7.5.8 Replacing a 8x 2.5-inch HDD backplane
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
In configuration with 24x 2.5-inch HDD/SSD/PCIe modules the third
backplane is a combo HDD backplane that also allows to install PCIes.
The replacing procedure is the same as a HDD backplane.
Preliminary steps
▶
"Locating the defective server" on page 49
.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
Hard disk drive (HDD) / solid state disk (SSD)
RX2540 M6 Upgrade and Maintenance Manual 179

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
