Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Concluding steps
▶
If applicable, "Switching on the server" on page 69.
▶
If applicable, rescan available devices from your OS.
▶
If applicable, "Installing the front cover with lock" on page
69.
7.5.10.5 Replacing a 16x EDSFF SSD backplane (top)
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 49
.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
▶
Release all EDSFF SSD modules and pull them out a few centimeters, see
"Removing an EDSFF SSD module" on page 194.
CAUTION
The HDD/SSD modules need not to be removed.
▶
If you want to remove them nevertheless, check if all HDD/SSD
modules are uniquely identified so that you can reinsert them
into their original bays.
▶
Release all dummy modules and pull them out a few centimeters, see
"Removing an EDSFF dummy module" on page 191
.
▶
"Removing the fan cage" on page 74.
Hard disk drive (HDD) / solid state disk (SSD)
RX2540 M6 Upgrade and Maintenance Manual 197
