The ODD (2) and the front VGA (1) are options in some configurations.
17.1.1.2 2.5-inch HDD/SSD configuration
Figure 369: Front side 16x 2.5-inch HDDs / SSDs / PCIe SSDs
Figure 370: Front side 24x 2.5-inch HDDs / SSDs / PCIe SSDs
1 Front VGA
2 Common Operation Panel
3
ODD / dummy cover
4 LTO drive / RDX drive / dummy cover
5 HDDs / SSDs / PCIe SSDs / dummy
modules
The ODD (3), the LTO drive or RDX drive (4) and the front VGA (1) are options
in some configurations.
Appendix A
536 Upgrade and Maintenance Manual RX2540 M6
