Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

4.2 Removing the front cover with lock
Figure 2: Turning the key
▶
Insert the key.
▶
T
urn the key in open position.
Figure 3: Removing the front cover
▶
Push in the lock on the left side (1) and remove the front cover in a slight
angle from the front (2).
4.3 Shutting down the server
CAUTION
▶
For more information, see "Important information" on page
35
.
This step is only required when upgrading or replacing non-hot-plug
components.
Basic hardware procedures
52 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
