Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Position Logical drive
number
ServerView RAID Manager display name
one SAS controller two SAS controllers
[8] 8 Vendor Product (8) Vendor Product (1:0)
[9] 9 Vendor Product (9) Vendor Product (1:1)
[10] 10 Vendor Product (10) Vendor Product (1:2)
[11] 11 Vendor Product (11) Vendor Product (1:3)
[12] 12 Vendor Product (12) Vendor Product (1:4)
[13] 13 Vendor Product (13) Vendor Product (1:5)
[14] 14 Vendor Product (14) Vendor Product (1:6)
[15] 15 Vendor Product (15) Vendor Product (1:7)
7.5.1.2 Configuration with up to 24 HDD/SSD/PCIe SSD modules
HDD/SSD
Figure 70: Configuration with up to 24 2.5-inch HDDs/SSDs
HDD/SSD
PCIe SSD
Figure 71: Configuration with up to 16 2.5-inch HDDs/SSDs and up to eight 2.5-inch PCIe
SSDs
Hard disk drive (HDD) / solid state disk (SSD)
160 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
