System state Power-on
indicator
Time
m Active area BIOS boot check
completion
Recovery area BIOS restore
Attention: the Power-on indicator is
not green but is reading the active
area BIOS and updating the recovery
area.
white on About 5 minutes
n Recovery area BIOS restore
completion
Record of the following message on
SEL.
BIOS TFTP or HTTP/HTTPS flash
OK (Recovery area)
white on -
Section d, f, h and l: the time it takes depending on memory and the number of
PCI cards installed. The above is the result of actual measurement without
loading a PCI card with two 8G memory modules.
From section c on, user can connect to iRMC web interface.
From section d onward, the screen will be displayed on the connected display.
Please check the screen.
17.2.2.4
Indicator on the ODD
ODDs may have an indicator or not.
Appendix A
556 Upgrade and Maintenance Manual RX2540 M6
