Figure 382: Indicator on the ODD (example)
1 Activity indicator
Activity indicator (1)
Status Description
off The ODD is inactive.
green on The storage medium is being accessed.
17.2.2.5 Indicators on hot-plug HDD / SSD / PCIe SSD / EDSFF SSD
modules
Figure 383: Indicators on an HDD / SSD / PCIe SSD module
1 Access indicator 2 Error indicator
Appendix A
RX2540 M6 Upgrade and Maintenance Manual 557
