Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

CPU
CPUn
iMC
0
1
2
3
DDR CH
0
1
0
1
0
1
0
1
Slot
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
Socket
1
A
2
A
1
B
2
B
1
C
2
C
1
D
2
D
1
E
2
E
1
F
2
F
1
G
2
G
1
H
2
H
#DIMMs
8
D
D
D
D
D
D
D
D
16
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D DDR4 DIMM is installed
10.2.4 DDR4 and Optane PMem - memory population
rules
–
Optane PMem population is limited to several patterns.
–
The same DDR4 DIMM type and capacity are used for each DDR4 and
Optane PMem population.
–
For Memory mode (MM), DDR4 and Optane PMem capacity ratio must be
between 1:4 and 1:16.
–
For App Direct (AD) mode, DDR4 and Optane PMem capacity ratio must be
between 1:1 and 1:8.
–
For App Direct (AD) mode, Optane PMem modules can be populated
symmetrically or asymmetrically across sockets.
–
Rank sparing mode is not supported.
Optane PMem population and supported DDR4 DIMM may change in
the future according to Intel’s validation result or specification-change.
Main memory
334 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
