Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Concluding steps
▶
"Installing the air duct" on page 79.
▶
"Reassembling" on page
60.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 69.
▶
If applicable, "Installing the front cover with lock" on page 69.
▶
"Resuming BitLocker functionality" on page 105.
After replacing memory modules, the Memory Status of them are reset
to
Enabled automatically and CSS LED is off.
If CSS LED is blinking after they are replaced, check the Memory
Status in the Configuration menu of the BIOS.
10.6 Handling memory dummy modules
It is required to install dummy modules in free memory slots. There are
different dummy modules available. The variants can be mixed.
Removing a memory dummy module
▶
Eject the desired dummy module by pressing out the securing clips at each
end of the memory slot.
▶
Remove the ejected dummy module.
Installing a memory dummy module
▶
Press the securing clips on both sides of the memory slot concerned
outward.
Main memory
RX2540 M6 Upgrade and Maintenance Manual 343

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
