13.3 Optical disk drive (ODD)
13.3.1 Storing the ODD latch
Figure 255: Storing the ODD latch
The ODD latch is fastened with two screws to the cross bar (see circle).
13.3.2 Installing the ODD (2.5-inch chassis)
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for cover 2)
–
T
orx Plus 6 screw driver (not valid for Japan)
– Phillips PH1 / (+) No. 1 screw driver (Japan)
Accessible drives
RX2540 M6 Upgrade and Maintenance Manual 387
