Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Removing the defective 3.5-inch HDD module
▶
Remove the HDD module, see "Removing a 3.5-inch HDD module" on
page 149.
▶
If applicable, remove the HDD from the installation frame, see "Handling
HDDs or SSDs without installation frame" on page 136.
Installing the new 3.5-inch HDD module
▶
If applicable, install the HDD in the installation frame, see "Handling HDDs
or SSDs without installation frame" on page
136.
▶
Install the HDD module, see "Installing a 3.5-inch HDD module" on
page 147.
Concluding steps
▶
If applicable, "Installing the front cover with lock" on page 69.
▶
If the HDD is configured using a RAID controller with a RAID level higher
than "0", the rebuild will start automatically, see "Performing a RAID array
rebuild" on page 106.
7.4.5 Replacing the 10x 3.5-inch HDD backplane
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 49
.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
Hard disk drive (HDD) / solid state disk (SSD)
152 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
