9.8.2 Removing an expansion card from a riser module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Suspending BitLocker functionality" on page 87
.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
▶
Remove the corresponding riser module, see "Removing a riser module" on
page 70.
Removing the expansion card from a riser module
▶
If necessary, disconnect the cables from the expansion card.
▶
If applicable, "Removing SFP+ transceiver modules" on page 245.
Expansion cards and backup units
284 Upgrade and Maintenance Manual RX2540 M6
